【适用范围】

用于染色牢度试验中的耐光色牢度及耐气候色牢度试验，也可用于油漆、颜料、涂料、橡胶、塑料、木地板以及纸张等其它材料的耐光色牢试验和光老化试验。

【相关标准】

ISO105-B02、GB/T8427、GB/T15102-2006、GB/T14576、GB/T15104-2006、GB/T8430、AATCC TM16、ISO105-B04

YS-611-3Z Xenon Arc Light Fastness Tester

【Scope of application】:
It is used for light fastness and climate fastness tests in dyeing fastness tests, and can also be used for lightfastness and photoaging tests for paints, pigments, coatings, rubber, plastics, wooden floors and other materials such as paper.
ISO105-B02 GB/T8427  GB/T15102-2006  GB/T14576   GB/T15104-2006   GB/T8430   AATCC TM16    ISO105-B04

【The compatible standards are as follows】

International  Standard: ISO

Europe Standard: CE    RoHS

American Standard: AATCC  ASTM

German Standard: DIN

Janpan Standard: JIS

China  Standard: GB FZ

[Instrument features]:
1. Digital setting of light intensity, real-time monitoring, automatic adjustment to meet the stability requirements of different standards for test light source (can switch 420nm; 300-800nm or 300-400nm band monitoring);
2. Standard blackboard thermometer (BST) and blackboard thermometer (BPT) can be selectively used, and the same station (equidistant) as the sample can be detected, which truly reflects the test status of the sample;
3. The measured data is processed by the CPU and displayed on the color screen in the form of numbers, charts, curves, etc., without stopping for observation.
4. Microchip 32-bit intelligent CPU, efficient real-time control, to ensure accurate reproduction of the same test environment;
5.7-inch color screen display control, a variety of test monitoring modes (animation numbers, charts), easy to control, intuitive and clear;
6. All specimen clips are timed separately, and different specimens can be tested on the same machine, which is convenient for testing and monitoring and reduces operating costs;
7. Rated 1500W long arc xenon lamp technology, high efficiency and energy saving, real simulation of daylight spectrum;
8. Industrial temperature control (refrigeration) system, the temperature adjustment in the test chamber is fast and stable;
9. Built-in self-circulation system and air filtration system, which greatly reduces environmental requirements;
10. European traceability spectrum analyzer, multi-measurement calibration;
11. Quality assurance that one test can run continuously for 1000 hours.
12. The test data can be copied directly from the instrument using a USB flash drive, which is more conducive to the needs of a variety of site test environments.
【Technical Parameters】:
1. Test chamber temperature control range: (20~50)°C; Accuracy: ±2°C
2. Humidity control range of test chamber: (15~95)%RH, accuracy: ±5%RH
3. Test time control range: 0~9999:59 (h:min); Accuracy: ±1min
4. Irradiance control range:
(0.80～1.60) W/m2/420nm Accuracy: ±0.02W/m2/420nm
(25-60) W/m2/300-400nm Accuracy: ±2W/m2/420nm
(300-650) W/m2/300-800nm Accuracy: ±10W/m2/420nm
Digital setting, automatic compensation
5. Xenon light source:
a. Xenon arc lamp rated power: 1.4kW;
b. Color temperature: 5500K~6500K;
6. Specimen:
a. Specimen rack rotation speed: 5rpm; accuracy: ±3 seconds
b. Specimen clip distribution diameter: 286mm
c. Size and number of specimen clips:

d. Each specimen clip is timed separately: range: 0min~9999:59 (h:min); Accuracy: ±1min
e. Specimen thickness: ≤3mm
7. Standard Black Label Thermometer (BST) range: (30~75)°C; Resolution: 0.1°C, Accuracy: ±2°C
   Or optional blackboard temperature (BPT) range: (30~70)°C, resolution: 0.1°C, accuracy: ±2°C
8.7-inch touch screen operation
9. Power supply: AC220V±10% 50Hz 5.5kW
10. Overall dimensions: 1010mm×720mm×1767mm(L*W*H)
